PE pipe

PE pipe (polyethylene pipe) can be widely used in urban water supply, sewage treatment and farmland irrigation, gas transmission and transportation of various corrosive chemicals, and can be used as a protective casing for communication cables to protect the cables from external damage.

Commodity name： PE pipe

Classification:

Geotube

WhatsApp:

Email:

Delivery Time

10-15 days after receiving payment

Delivery Method

Send in the best possible way

Delivery Time

Usually 15-30 days

Product Description

PE pipe, or polyethylene pipe, is a common plastic pipe.

It has the following salient features:

1. Strong corrosion resistance: It can resist the erosion of various chemical substances and has a long service life in harsh soil and water environments.

2. Good flexibility: It can be bent and coiled, adapting to complex construction terrain and conditions, and reducing the use of pipe fittings.

3. Good hygienic performance: the material is non-toxic, will not cause pollution to the transported medium, complies with hygienic standards, and is often used for drinking water transportation.

4. Reliable connection: using hot melt or electrofusion connection, the interface strength is higher than the pipe body, ensuring the sealing and stability of the pipeline system.

5. Good low-temperature impact resistance: It can still maintain good toughness in low-temperature environments and is not prone to brittleness.

National standard nominal wall thickness of water supply pipe
GB/T 13663.2-2018	Nominal Size
	SDR41	SDR33	SDR26	SDR21	SDR17	SDR13.6	SDR11	SDR9
	PE80 Nominal Press (Mpa)
	0.32	0.4	0.5	0.6	0.8	1.0	1.25	1.6
	PE100 Nominal Press (Mpa)
	0.4	0.5	0.6	0.8	1.0	1.25	1.6	2.0
DN(mm)	TK(mm)	TK(mm)	TK(mm)	TK(mm)	TK(mm)	TK(mm)	TK(mm)	TK(mm)
16	-	-	-	-	-			2.3
20	-	-	-	-	-		2.3	2.3
25	-	-	-	-	-	2.3	2.3	3.0
32	-	-	-	-	2.3	2.3	3.0	3.6
40	-	-	-	2.3	2.4	3.0	3.7	4.5
50	-	-	2.3	2.4	3.0	3.7	4.6	5.6
63	-	-	2.5	3.0	3.8	4.7	5.8	7.1
75	-	-	2.9	3.6	4.5	5.6	6.8	8.4
90	-	-	3.5	4.3	5.4	6.7	8.2	10.1
110	-	-	4.2	5.3	6.6	8.1	10.0	12.3
125	-	-	4.8	6.0	7.4	9.2	11.4	14.0
140	-	-	5.4	6.7	8.3	10.3	12.7	15.7
160	-	-	6.2	7.7	9.5	11.8	14.6	17.9
180	-	-	6.9	8.6	10.7	13.3	16.4	20.1
200	-	-	7.7	9.6	11.9	14.7	18.2	22.4
225	-	-	8.6	10.8	13.4	16.6	20.5	25.2
250	-	-	9.6	11.9	14.8	18.4	22.7	27.9
280	-	-	10.7	13.4	16.6	20.6	25.4	31.3
315	7.7	9.7	12.1	15.0	18.7	23.2	28.6	35.2
355	8.7	10.9	13.6	16.9	21.1	26.1	32.2	39.7
400	9.8	12.3	15.3	19.1	23.7	29.4	36.3	44.7
450	11.0	13.8	17.2	21.5	26.7	33.1	40.9	50.3
500	12.3	15.3	19.1	23.9	29.7	36.8	45.4	55.8
560	13.7	17.2	21.4	26.7	33.2	41.2	50.8	62.5
630	15.4	19.3	24.1	30.0	37.4	46.3	57.2	70.3
710	17.4	21.8	27.2	33.9	42.1	52.2	64.5	79.3
800	19.6	24.5	30.6	38.1	47.4	58.8	72.6	89.3
900	22.0	27.6	34.4	42.9	53.3	66.2	81.7	-
1000	24.5	30.6	38.2	47.7	59.3	72.5	90.2	-
1200	29.4	36.7	45.9	57.2	67.9	88.2	-	-
1400	34.3	42.9	53.5	66.7	82.4	102.9	-	-
1600	39.2	49.0	61.2	76.2	94.1	117..6	-	-
1800	43.8	54.5	69.1	85.7	105.9	-	-	-
2000	48.8	60.6	76.9	95.2	117.6	-	-	-
2250	55.0	70.0	86.0	107.2	-	-	-	-
2500	61.2	77.7	95.6	119.1	-	-	-	-
