Bidirectional stretch geogrid
The extruded sheet or strip is stretched in the longitudinal and transverse directions using special stretching equipment to orient the molecular chains in the material in two directions, thereby improving its strength and rigidity. Made of high molecular polymer material, it has good corrosion resistance and aging resistance and can be used for a long time in various harsh environmental conditions.
- Commodity name： Bidirectional stretch geogrid
Delivery Time
10-15 days after receiving payment
Delivery Method
Send in the best possible way
Delivery Time
Usually 15-30 days
- Product Description
-
Excellent biaxial tensile performance: It can provide strong tensile strength in both longitudinal and transverse directions, thereby more effectively limiting the displacement and deformation of soil.
Good toughness and fatigue resistance: able to withstand repeated loads and less prone to fatigue failure.
High chemical stability: It has good tolerance to chemicals such as acids, bases, and salts.
The application of biaxial tensile geogrid is very extensive:
Highway and railway construction: used to enhance the stability of the roadbed, reduce road cracks and settlement.
Water conservancy engineering: such as reinforcement and anti-seepage of dams and channels.
Land improvement and reclamation: Improving the structure and mechanical properties of soil.
Ltem Tensile strength KN/m Elongation Rate % Tensile strength with 2% Srain KN/m Tensile strength with 5% Srain KN/m Logitudinal Traverse Logitudinal Traverse Logitudinal Traverse Logitudinal Traverse TGSG15-15 ≥15 ≥15 ≤13 ≤16 ≥5 ≥7 ≥8 ≥10 TGSG20-20 ≥20 ≥20 ≤13 ≤16 ≥8 ≥10 ≥10 ≥13 TGSG25-25 ≥25 ≥25 ≤13 ≤16 ≥8 ≥11 ≥11 ≥15 TGSG30-30 ≥30 ≥30 ≤13 ≤16 ≥12 ≥13 ≥15 ≥15 TGSG35-35 ≥35 ≥35 ≤13 ≤16 ≥12 ≥15 ≥15 ≥18 TGSG40-40 ≥40 ≥40 ≤13 ≤16 ≥13 ≥16
Key words:
Bidirectional stretch geogrid
Factory Appearance
The main products are HDPE unidirectional geogrid, LDPE geomembrane, composite geomembrane, geogrid welding machine, geogrid (HDPE unidirectional Geogrid, bidirectional Geogrid, steel-plastic Geogrid, fiberglass geogrid) Geotechnical pipe, HDPE double wall corrugated pipe, HDPE drain pipe, Fiberglass Geogrid) Geotechnical pipe, HDPE double wall corrugated pipe, HDPE drain pipe, PE pipe, Non-woven geotextiles, composite geotextiles, geobags) geonet, Composite drainage network, plastic geomesh, geoglass, bentonite synthetic blanket, plastic film, PO film PE film and other geosynthetic materials.
Packaging And Delivery
Our annual outputs have exceeded 300 million square meters, Our main markets are Europe, North America, South America, Australia, some African and Asian countries. exporting to more than 40 countries. We assure not only steady production capability and on-time shipments, but also professional skilled workers and better the quality of products For the satisfaction of our customers.
Application Cases
These products have been widely used in more than 300 projects in the fields of environmental protection, expressways, railways, golf courses, etc. The company has accumulated rich engineering experience. It enjoys a reputation of "good quality and high standard" in the industry, and has received unanimous praise from the engineering community and a large number of users. Moreover, it has established close cooperative relationships with dozens of scientific research and design units and universities across the country.
Customer visit
The company always adheres to the business philosophy of "science and technology first, integrity-based, and win-win coexistence", and sincerely hopes to cooperate extensively with friends at home and abroad to jointly draw a magnificent blueprint!
Customer Feedback
WHY CHOOSE US
High Cost Performance
High quality products and great prices.
Guarantee Quality
Product quality meets international quality inspection standards.
Advanced Equipment
We have introduced the latest production equipment.
Good Service
We have a professional team to serve you.
FAQ
About product prices?
Can you send samples?
How long is your delivery time?
How many SQM of one container can load?
Can I go to your factory to visit?
What is the roll width of your Geotextile Geomembrane ?
